QS165 50H 10kW 72V Brushless Mid Drive Motor BLDC PMSM 428 14T

QS165 50H 10kW 72V BLDC PMSM Mid Drive Motor with 428 14T Sprocket

Motor Specifications:

• Motor Type: PMSM motor with hall sensors
• Rated Voltage: 48-96V
• Rated Power: 10,000W
• Peak Power: 20000-35000W, depending on cooling
• Peak Battery Current: 400A
• Peak Phase Current: 1000A
• RPM: 6200RPM
• No-Load RPM: 10,000RPM
• Max Speed: 95-150 KPH / 60-95 MPH
• Magnet Height: 50mm, 5 pole pairs
• Thermal Sensor: KTY83-122
• Net weight: 13.52kg
• Phase angle: 120°
• Phase wire: 30mm²
• Maximum Torque:  72N.m without Reduction ratio, 360N.m with a 1 : 5 Gear Reduction ratio
• Max Efficiency: 94%
• Working Temperature: 70-110℃, peak 130℃
• IP67 Water Resistant
• Colour: Black

Package Includes:

1x QS165 50H 10kW Mid Drive Motor

1x 428 14T Sprocket Adapter
